AES 210HVOUTDOOR C&I ENERGY STORAGE CABINET
The simplicity of residential solar at scale for the C&I market.
The AES 210HV integrates with C&I hybrid inverters for simpler installation
Sol-Ark 60K & Solis 30 - 60K and more to come
Versatile, scalable, and cost efficient energy storage for community, commercial, and industrial applications.
Residential Buildings
Commercial Offices
EV Charging Stations
Restaurants, Convenience & Grocery Stores
Banks, Pharmacies &
Schools
Data Centers, Warehouses & Industrial Facilities
Features & Benefits
Simple InstallationBy combining critical components into one system and integrating with C&I hybrid inverters, we remove the need for complex microgrid controllers, EMS controllers, and additional transformers—making installation as straightforward as residential setups. | Easily ScalableFrom 200 kWh to 4.8 MWh, our modular platform is designed to easily expand without the complexity of traditional systems, adapting the solution to varying projects and allowing them to grow without extensive redesigns. |
Cost-Efficient and Faster ROILess required system components translate to reduced installation time and labour, lowering overall project costs, making C&I solar projects more accessible and profitable, even at smaller scales. | Supports Microgrid & Off-Grid FunctionalitySupports demand response, peak shaving, and backup power for grid-tied applications, and provides consistent, grid-independent power for off-grid and microgrid scenarios. |
AES 210HV Documents
① Audible and Visual Fire Alarms
② Heat and Smoke Detector
③ Passive Deflagration Vent
④ Thermal Management System
⑤ Battery Modules (x4)
⑥ High Voltage Control Box
⑦ Manual Service Disconnect (x4)
⑧ Dehumidifier
⑨ Aerosol Fire Extinguishing Device
⑩ LYNK II Communication Gateway
⑪ LED Indicators
⑫ Emergency Stop Switch
.
Case Study
Off-Grid Energy Resilience at Springville Foods, PA
A Community Grocery Store Trades Diesel for Clean, Reliable Power with Discover AES 210HV and Sol-Ark
Location: Eastern Lancaster County, Pennsylvania
Client: Springville Foods
Installer: CB Solar, LLC
Distributor and Technical Design Support: Zonna
Energy
Storage System: Discover AES 210HV
Inverter Platform: Sol-Ark 60K-3P-480V (x2)
PV Array Size: 75 kW Ground Mount
Commissioned: April 2025
INVERTER PARTNER INTEGRATIONS
AES 210HV & Sol-Ark
Discover's AES 210HV high-voltage outdoor battery cabinet is fully compatible with the Sol-Ark 60K-3P hybrid inverter, delivering a turnkey energy storage solution ideal for commercial and industrial applications.
AES 210HV & Solis
Discover’s AES 210HV battery cabinet pairs seamlessly with the Solis S6-EH3P (30–60kW) hybrid-inverter series, offering a simple, scalable, and proven energy storage solution for commercial and industrial applications.
